TGR-M-NS

TGR-M-NS Silikonfreie Wärmeleitpaste hoch thermisch leitfähig

TGR-M-NS is high performing silicone-free thermal grease based on an ester oil matrix. It is ideal for use in applications where a very good and highly reliable thermal transfer must be achieved. Due to the specific formulation and filling with ceramic particles the material has a high thermal conductivity. By its use the thermal contact is maximised, hence the total thermal resistance is minimised.

PROPRIETÀ
  • Thermal conductivity: 2.4 W/mK
  • Silicone-free
  • Dispensable
  • Almost zero pressure at assembly
  • Dielectric strength
  • Operating temperature range: -40 to 150°C
DISPONIBILITÀ
  • Syringes 340 ml
  • Jars 1 kg
ESEMPI DI APPLICAZIONE

Thermal link of:

  • LED Boards
  • Power modules
  • RDRAMs memory modules
  • Flip Chips, DSPs , BGAs, PPGAs

For use in Automotive applications / Power electronics / Light technology / Industrial PCs

OVERVIEW
PropertyUnitTGR-M-NS
MaterialKeramik gefüllte Wärmeleitpaste
ColourWeiss
Densityg / cm³3,2
Viskosität (Brookfield @ 10 rpm, 25 °C)Pas110
RoHS Conformity2015 / 863 / EUYes
Thermal
Thermal ConductivityW/mK2,4
Operating Temperature Range°C- 40 bis + 150
Storage Temperature°C< 35 °C
Shelf Life (from Date of Manufacturing, unopened)Months @ RT12
Electric
Dielectric StrengthkV / mm4,5

/
